London Aluminium Driveway Gates | Diagonal Infill

Buy Online Today

London Aluminium Driveway Gates | Diagonal Infill

The London Aluminium Driveway Gates are an innovative and modern solution for your primary vehicle access point, offering additional privacy and protection benefits. They feature an attractive and desirable diagonal infill panel and are available to buy online in width and height variations to suit your space and are exceptional value for money.

Ordering Sizes

The width and height measurements displayed in the drop-down menu reflect the physical dimensions of the gates. Due to the hinges, locking mechanisms and other fittings, further clearance is required to enable proper installation. To calculate the size of the gap needed between your brickwork, posts or different support structure, please refer to the table found in the product description below.

Delivery:
Please allow approximately 3 - 4 weeks lead time for delivery of this product.

Select the Size You Need (gates are sold as a pair):

Other Options & Accessories

Select the Colour:
Do You Need a Factory Fitted Handle & Lock?:
Do You Need a Drop Bolt?:
Do You Need Posts?:

The London Aluminium Driveway Gates will add a touch of class to your driveway. The robust structure and elegant diagonal boarded infill panels of these modern gates make a striking aesthetic statement. The powder-coated paint finish is long-lasting and resists chipping, fading, and weathering. They come with four wall-mountable adjustable hinges and two floor-mounted hinges, allowing you to choose the installation method that best suits the layout of your entrance.

London Aluminium Driveway Gates Specification

  • This modern design is suitable for most types of property. They are ideal for those who want to create a stylish, contemporary statement.

  • With a fresh minimalist look, they are perfect for anyone looking for a premium product at a competitive price.

  • Available as standard in a choice of black or anthracite grey paint finishes.

  • Sturdy and robust, they will withstand harsh weather and environmental conditions and will not twist or deform, so you can depend on them to secure your property.

  • They are constructed from durable aluminium components to ensure maximum longevity.

  • The combination of solid and reliable materials and a user-friendly installation makes them ideal if you need to secure your property quickly.

  • Aluminum is an ideal moisture-resistant alternative to wood because it has natural corrosion resistance and doesn't fade under sunlight or extreme temperatures.

  • The London design is available to purchase online in a selection of width and height configurations to meet your needs.

  • The gate hardware is adaptable for electric and manual closing and opening (please note that the handle and lockset must be specified when ordering manual gates).

  • The surface-mounted adjustable hinges are a quick and easy install. They can be mounted directly onto aluminium posts or any suitable masonry surface.






Ordering Sizes

Remember that all measurements listed in the drop-down menu correspond to the total physical width of the two gates (when placed side by side). These dimensions do not include the additional space requirement for the hinges, locking mechanism, and ground clearance. The height is calculated by measuring the distance between the top and bottom of the vertical rails.

Use the chart listed below as a reference to determine the proper gap size that you will require between your brick walls or support posts.

Opening Size Requirements

Aluminium driveway gates opening size requirements diagram

If you do not see your size, please let us know. We can work with you to find a solution.

Physical Width = 3000mm

The opening should measure 3030mm - 3060mm between your walls or posts

Physical Width = 3250mm

The opening should measure 3280mm - 3310mm between your walls or posts

Physical Width = 3500mm

The opening should measure 3530mm - 3560mm between your walls or posts

Physical Width = 3750mm

The opening should measure 3780mm - 3810mm between your walls or posts

Physical Width = 4000mm

The opening should measure 4030mm - 4060mm between your walls or posts

Height Dimensions

The height of the walls or posts must be at least 100mm greater than the physical height of the gates. This will then ensure that there will be enough room for the fittings to be installed at a safe distance from the top and bottom.






What is Included with the Double Gates as Standard?

4 x Wall Mounted Adjustable Hinges

2 x Floor Mounted Hinges




Do you Need to Purchase Aluminium Posts?

The post system is compatible with above and below-ground installations. When mounting onto concrete or other hard surfaces, you can connect it using the base plate, which acts as a foundation for each post. Alternatively, you can bury the posts in the ground and reinforce them with concrete.

Specification

Our aluminium posts provide a free-standing option for added strength and weight capacity. Each post is produced from a 3.5mm thick profile, meaning they can handle the weight of the gates and keep them securely in position. We can supply these items in black or anthracite grey (as shown in the menu), so you can match them to your gates if required.




Confused About Ordering Sizes?

Please don't hesitate to contact us regarding your order. Our gates are made to your specification, and we want you to be 100% satisfied with the product. If you are uncertain of your exact requirements, please check the size with us before placing your order, as mistakes can prove costly to rectify.

Made to measure sizes are available






Installation Instructions

Please follow the steps described in the instructions to make your installation as smooth as possible. We want you to enjoy your new product for many years ahead.

How to Install onto Brickwork ►

How to Install onto Posts ►

How to install aluminium driveway gates to brickwork How to install aluminium driveway gates to posts

Colour Chart

Colour chart

Component Sizes

London design component sizes

Sizing diagram for diagonal inflll
